Cross-Cut machine for logs

Brand:

WIREX

The Cross-Cut machine for logs is an essential piece of equipment in the timber processing industry, designed to enhance efficiency and precision in cutting logs into shorter lengths. This machine operates by employing a series of sharp blades or saws that slice through the wood with minimal effort, allowing for quick and accurate cuts.

The  machine can be adjusted to handle various log sizes and types, making it suitable for different applications, from lumber production to firewood processing. With its powerful motor the machine significantly reduces the time required for log processing, enabling operators to maximize productivity. Equipped with safety features, the machine ensures a safe working environment for operators, minimizing the risk of accidents. Built with robust materials, and designed to withstand the rigors of heavy use in outdoor and industrial settings, ensuring longevity and reliability.

Cross-Cut machine for logs is ideal for sawmills where logs need to be cut into specific lengths for further processing. Perfect for businesses that supply firewood, allowing for quick and consistent cuts.

Ask about product

Optional equipment

  • more variations of cut
  • roller conveyors
  • cross cutting workpiece longer than 4 m (individual quotation)
  • infeed chain conveyor with function of disposal of excessive logs to side buffer (side conveyor wall hydraulically lowered)
  • output chain conveyor with function of side disposal of logs
Technical data
DataValue
Dimensions
  • length 1000mm
  • width 2780mm
  • height 3000mm
Weight
  • cutting head support: 1900 kg
  • conveyors: 2500 kg
Dimensions of infeed workpiece
  • length 2500 – 4000 mm
  • diameter 80 – 480 mm (capacity without cutting up to 600 mm)
Main motor power16,2 kW
Power demand24 kW
Conveyor feed
  • smooth, inverter controlled
  • speed rate 1 – 20 m/min
Twin-chain conveyors, integrated
  • length on infeed side 6000 mm
  • length on output side 5000 mm
ControlsPLC 7 ” touch panel placed on a movable operator panel
HydraulicRaw material clamping jaws – 4 pcs.
Cutting options
  • 800 mm
  • 1200 mm
Circular blade
  • diameter 1200 mm
  • rapid blade return function after cut
  • rapid blade drop fuction to the cut workpiece
