Tel: +44 (0) 197 825 4472CZ-2 Horizontal Twin Resaw
Efficient Timber and Pallet Plank Cutting
The CZ-2 horizontal twin resaw is engineered to efficiently convert two- or three-sided flitches into high-quality planks, scantlings, and pallet boards. Serving as a cost-effective alternative to a multirip saw, the CZ-2 delivers superior timber processing efficiency while reducing waste. Its narrow kerf of approximately 2–2.5 mm minimizes sawdust, making it an ideal solution for manufacturers focused on sustainable wood production.
For 3 head version look here.
CZ-2 Horizontal Twin Resaw – Efficient Timber Resawing for Planks and Scantlings
Built with a robust design and intuitive controls, the CZ-2 ensures reliable performance and ease of operation, even in demanding production environments. Perfect for lumber processing, pallet manufacturing, or woodworking facilities, this horizontal twin resaw offers precision, versatility, and consistent high-quality output.
Upgrade your production line with the CZ-2 resaw to enhance workflow, maximize yield, and achieve precise, efficient cutting for all your timber and pallet plank needs.
Optional equipment
- main motors shift to 2 x 8,1 kW or 2 x 12 kW
- main belt conveyor width shift to 300 mm
- return belt conveyor 300 x 3000 mm
- spring down-holder shift to pneumatic one
- rotary down-holder with electrical feed (max workpiece height 250 mm)
| Data | Value |
|---|---|
| Dimensions |
|
| Weight | 1100 kg |
| Dimensions of infeed workpiece |
|
| Dimensions of obtained flitch | minimal thickness 75 mm per side |
| Main motors power | 2 x 6 kW |
| Power supply | 400 V (3 phase) |
| Conveyor feed |
|
| Band wheels diameter | 600 mm |
| Band saw specification |
|
| Workpiece down-holder |
|
| Thickness of cut setting | manual |
| Capacity per hour | up to 3 m3 |
